(USA and Canada only)
Optical Isolation Input to Output
½ cycle maximum
25 to 65 Hz (operates at 400 Hz with six times
Coupling Capacitance Input to Output
8 pF maximum
200 volts per microsecond
Snubbed for rated current at 0.5 power factor
Nominal AC Line Voltage
Nominal Current Rating
1 cycle Surge (Amps) Peak
Nominal Signal Input
Signal Pick-up Voltage
3VDC (32V allowed)
Signal Drop-out Voltage
Peak Repetitive Voltage
Operating Voltage Range (Volts AC)
I2t Rating t=8.3 (ms)
* Ambient temperature will affect the current rating. For details, see the Thermal Ratings charts in the Solid State Relays Data Sheet (form 0859).
** θjc = Thermal resistance from internal junction to base. Maximum internal junction temperature is 110 °C.
