$27.25 (USA and Canada only)
Units
G4IDC5*
G4IDC5B
G4IDC5D*
G4IDC5G*
Input voltage range
VDC VAC
10–32 12–32
4–16 4–16
2.5–28 —
35–60 35–60
Key feature
—
Higher speed
High speed
Input current at maximum line
mA
25
45
30
6
Isolation, input-to-output (transient): 1 ms 1 minute
V V
4000 1500
Turn-on time
ms
5
0.05
1
10
Turn-off time
0.1
1.5
Input allowed for off-state
mA, V
1, 3
0.7, 1
0.2, 1
0.7, 7
Nominal output supply voltage
VDC
Output supply voltage range
4.5–6
Output supply current at nominal logic voltage
12
Input resistance (R1 in schematic)
ohms
1.5 K
300
900
10 K
Control resistance (Rc in schematic)
220
470
Output voltage drop
V @ 50 mA
0.4
Output current (sinking)
50
Output leakage with no input
microamps @ 30 VDC
100
Transistor
V breakdown
Temperature: Operating Storage
°C °C
-30 to +70 -30 to +85
Opto 22’s G4 DC input modules are used to detect on/off DC voltage levels. This document includes descriptions, specifications, and wiring and dimensional diagrams for Opto 22’s G4 DC output modules:
Now you can safely and reliably sense and switch industrial-level electrical loads with your Raspberry Pi® and Opto 22 industrially hardened digital I/O. This Selection Guide describes compatible I/O racks and modules, power supplies, and accessories that work with the Raspberry Pi and the Digital I/O Carrier Board for the Pi (OPTO-P1-40P). Specifications, dimensional drawings, and wiring diagrams for racks and I/O modules are included. For code samples and steps to get started, also see developer.opto22.com.
The G4 Digital I/O Data Book provides complete details on every G4 digital I/O product component, including adapter cards, I/O modules, and mounting racks.
