IOCONTROLPRO
Hover over image to zoom in

IOCONTROLPRO

Availability: Obsolete
Download
OBSOLETE  ioControl Professional

Production Specification

*** This product is OBSOLETE and no longer available. ***

For new development,  use PAC Control, part of the PAC Project software suite and designed for SNAP PAC controllers. If you do not need Ethernet link redundancy, segmented networking, support for legacy FactoryFloor I/O units, or the ability to import OptoControl strategies, see PAC Control Basic.

To compare product features, see Legacy and Current Product Comparison and Compatibility Charts.

-----------------

ioControl Professional is a legacy flowchart-based programming language for building control, monitoring, and data acquisition applications. Available separately or as part of the ioProject Professional software suite, ioControl also builds the underlying database for ioDisplay human-machine interfaces and OptoOPCServer.

This product includes software and documentation in Adobe Acrobat PDF format on a CD. It also includes complete printed documentation.
*** This product is OBSOLETE and no longer available. ***

ioControl Professional
can be purchased separately or as part of the ioProject Professional software suite.

Installation requirements:
  • Computer with at least the minimum processor required for your version of Microsoft(R) Windows(R), running Windows XP or Windows 2000(R)(with SP4) workstation operating system. 1 GHz Pentium(R) class or better recommended. Must have Ethernet capability and at least 128 MB RAM (256 MB recommended).
  • VGA or higher resolution monitor (Super VGA recommended), minimum size 800x600 with small fonts.
  • Mouse or other pointing device. Printer optional.
  • Available hard disk space required: 30 MB

ioProject Software Suite Data Sheet

*** NOTE:  Three products in this suite (IOPROJECTBAS, IOPROJECTPRO, and IOCONTROLPRO)  are OBSOLETE and no longer available.***

This data sheet describes Opto 22's legacy ioProject software suite, which provides control and HMI development tools for a SNAP Ethernet-based control system. The ioProject suite includes ioControl, ioDisplay, OptoOPCServer, and ioManager.

NOTE: For new development, use a SNAP PAC controller and PAC Project software.

ioControl User's Guide

The ioControl User's Guide includes programming instructions and tips for developing control strategies to run on SNAP Ultimate controller/brains and SNAP-LCE controllers. ioControl is part of the ioProject software suite.

ioProject Readme Notes

Readme for ioProject Basic and Professional, the legacy versions of PAC Project. Includes information on features, enhancements, and bug fixes for each ioProject application: ioControl, ioDisplay, OptoOPCServer, ioManager, and ioUtilities.

ioControl Software README

The README file lists revision changes made to ioControl software.

ioProject 7.1 Release Notes

This document describes the 7.1 release of the ioProject Basic and ioProject Professional software suites, including applications, installation, new features, and enhancements.

ioControl Commands Quick Reference Card

Quick reference card for using ioControl, including all standard ioControl commands and their OptoScript equivalents. ioControl is part of the ioProject software suite.

ioControl Command Reference

This command reference describes in detail all ioControl programming commands, or instructions. Use with form #1300, the ioControl User's Guide. ioControl is part of the ioProject software suite.

Message Queue Logger

This strategy and project demonstrate how to log messages from a controller's error (or "message") queue to the computer's hard drive. Having this information can make any troubleshooting needed easier.

The message log created provides a history of how your system runs under normal conditions. When problems occur, you will have a history of normal messages as well as error messages to help troubleshoot the cause.

The strategy and project were originally created in ioProject 7.0 Basic, and can be used with ioProject 7.0 and 7.1 as well as PAC Project 8.0, 8.1, and 8.2. It can also be used with Basic or Pro versions.

These are sample files. Before you download, read the Legal Agreement.

No videos or demos are available for this product.
