IOP-INT-MBTCP
Hover over image to zoom in

IOP-INT-MBTCP

Availability: Obsolete
OBSOLETE Modbus/TCP Integration Kit for ioControl

Production Specification

*** NOTE: This part is OBSOLETE and no longer available. ***
This Modbus/TCP Integration Kit for ioControl allows Opto 22 controllers using ioControl to connect via Ethernet to any Ethernet/TCP-Modbus device and communicate using the Modbus/TCP protocol.

This free Integration Kit contains a set of ioControl master subroutines, an example Modbus/TCP slave strategy, and ioDisplay master and slave projects to show communication between the example strategies and a Modbus device.
The following items are required before you can include the ioControl master subroutines in your strategy:
  • ioProject Basic (or Professional) 7.0 or newer
  • ioControl and the Modbus/TCP Integration Kit for ioProject installed on a PC
  • an Opto 22 ioProject controller with a firmware revision of R7.0c or newer

README for Modbus/TCP Integration Kit for ioControl

This README file lists the changes made to the Modbus/TCP integration kit for ioControl.

Modbus/TCP Integration Kit for ioProject

The Modbus/TCP Integration Kit for ioProject (Part # IOP-INT-MBTCP) allows Opto 22 controllers, using ioControl, to connect via Ethernet to any Ethernet/TCP-Modbus device and communicate using the Modbus/TCP protocol. The Integration Kit contains a set of ioControl master subroutines, an example Modbus/TCP slave strategy, and ioDisplay master and slave projects to show communication between the example strategies and a Modbus device.

This document explains how to use the integration kit. It assumes you already understand how to use ioControl, Modbus/TCP, and the Modbus device to be used.
