PAC-INT-ABDF1
Hover over image to zoom in

PAC-INT-ABDF1

$0.00 (USA and Canada only)

Availability: In stock
Download
Allen-Bradley DF1 Integration Kit for PAC Control

Production Specification

The Allen-Bradley DF1 Integration Kit provides users of Opto 22’s PAC Control software (version 8.0 and above) an easy method of communicating with Allen-Bradley drivers or PLCs using the DF1 protocol.

Opto 22 controllers can act as either a “master” or a “slave” device. They can be connected directly to the serial port on an Allen-Bradley PLC or to Data Highway networks using standard Data Highway interface devices.

The Allen-Bradley DF1 Integration Kit consists of a set of PAC Control subroutines, which can be called from any flowchart in the PAC Control strategy running on the controller.
The Allen-Bradley DF1 Integration Kit is suitable for use with any Opto 22 SNAP PAC controller running PAC Project Basic or Professional software, including:
  • SNAP PAC S-series controllers
  • SNAP PAC R-series controllers

Allen-Bradley DF1 Integration Kit For PAC Control Users Guide

The Allen-Bradley DF1 Integration Kit (Part # PAC-INT-ABDF1) provides users of Opto 22’s PAC Control software(version 8.0 and above) an easy method of communicating with Allen-Bradley drivers or PLCs using the DF1 protocol. Opto 22 controllers can act as either a “master” or a “slave” device. They can be connected directly to the serial port on an Allen-Bradley PLC or to Data Highway networks using standard Data Highway interface devices.
