*** NOTE: This integration kit is obsolete. The last available version has been moved to our FTP site (ftp://ftp.opto22.com). ***
The BACnet MS/TP Integration Kit for
PAC Project enables your Opto 22 PAC system equipped with a SNAP-PAC-S1 or SNAP-PAC-S2 controller to communicate with a BACnet MS/TP network via RS-485. BACnet is a communications protocol for building automation and control networks. MS/TP is a Master-Slave/Token-Passing specification of BACnet.
The integration kit contains the BACnet_Protocol and Master_Sub charts, which contain everything you need to use the BACnet MS/TP protocol in your own PAC Control strategy. It also includes a VAV Controller Polling example strategy that polls from 1 to 45 VAV (Variable Air Volume) controllers.
OBSOLETE Product
Requirements:
- PAC Project (Basic or Pro) 8.2a or higher
- SNAP-PAC-S1 or SNAP-PAC-S2 controller
*** NOTE: The BACnet MS/TP Integration Kit is obsolete. This document remains on our website for reference. ***
This README explains the BACnet MS/TP Integration Kit for PAC Project.
*** NOTE: The BACnet MS/TP Integration Kit is obsolete. This document remains on our website for reference. ***
The BACnet MS/TP Integration Kit for PAC Project™ (Part # PAC-INT-BAC) enables your Opto 22 PAC system equipped with a SNAP-PAC-S1 or SNAP-PAC-S2 controller to communicate with a BACnet MS/TP network. BACnet is a communications protocol for building automation and control networks. MS/TP is a Master-Slave/Token-Passing specification of BACnet. This guide describes the integration kit and how to use it.
No downloads are available for this product.
