PAC-INT-IEC60870-5
Hover over image to zoom in

PAC-INT-IEC60870-5

$0.00 (USA and Canada only)

Availability: In stock
Download
PAC Control Integration Kit for 60870-5-101 and 60870-5-104 Protocols

Production Specification

IMPORTANT: The IEC60870-5 Integration Kit for PAC Control is available as a free download from our website. It is provided as freeware in "as is" condition and may be used at your own risk. Product support is not provided.

The IEC60870-5 Integration Kit for PAC Project allows Opto 22 SNAP PAC controllers using PAC Control to connect via an Ethernet network and serial port or serial module and communicate using the 60870-5-101 and 60870-5-104 protocol.

It supports 60870-5-101 outstation over serial and Ethernet and 60870-5-104 outstation over Ethernet. The 60870-5 Outstation can connect to 1 – 4 masters using Ethernet and Serial ports.

The Integration Kit contains:
  • An example 60870-5 strategy containing the 60870-5 charts that are imported into a strategy to enable an Opto 22 controller to communicate as a 60870-5 outstation.
  • A set of PAC Control subroutines that are added to a strategy.
The 60870-5 strategy transmits message strings as specified in the 60870-5-101 Specification Version 2003 and 60870-5-104 Specification Version 2006.
Requirements:
  • An Opto 22 SNAP PAC controller with firmware R9.3a or later
  • A PC running PAC Control Professional 9.3a or later software and the 60870-5 Integration Kit for PAC Control
  • (Optional) A SNAP PAC Learning Center (to run the example strategy)
Requirements:
  • An Opto 22 SNAP PAC controller with PAC firmware R9.3a or higher.
  • A PC running PAC Control Professional 9.3a or later, and the 60870-5 Integration Kit for PAC Control.
  • (Optional) A SNAP PAC Learning Center (to run the example strategy).

IEC60870-5 Integration Kit for PAC Project Guide

IMPORTANT: The PAC-INT-IEC60870-5 Integration Kit for PAC Control is available as a free download from our website. It is provided as freeware in "as is" condition and may be used at your own risk. Product support is not provided.

The IEC60870-5 Integration Kit for PAC Project (Part #PAC-INT-IEC60870-5) allows Opto 22 SNAP PAC controllers using PAC Control to connect via an Ethernet network and serial port or serial module and communicate using 60870-5-101 and 60870-5-104 protocol. This guide describes the integration kit and how to use it.

No downloads are available for this product.

Video: SNAP PAC System Overview

This overview describes the four integrated components of the SNAP PAC system: software, controllers, brains and I/O. This hardware and software system is designed for industrial control, remote monitoring and data acquisition.
