When added to a groov EPIC® processor (GRV-EPIC-PR1 or GRV-EPIC-PR2) or the groov RIO module GRV-R7-MM2001-10, this development license gives you access to all of the features of Ignition Edge® Panel version 8, to create local visualization with the Perspective module. Your Perspective HMI can run on your groov EPIC processor's touchscreen and any external monitor attached to your processor. In addition:

• Connect to PLCs and devices through included Ignition Edge OPC UA drivers (AB, Siemens, Omron, and more; nearly unlimited device connections)
• Connect to OPC UA servers with Ignition Edge OPC UA client (unlimited server connections)
• Transmit MQTT Sparkplug B message through the included Ignition Edge MQTT Transmission module
• Allow access to Ignition's OPC UA Server from external sources
• Store 35 days of historical and event logging (alarm, auditing) data in your groov device’s internal storage; allow access to this information from other gateways through Sync Services
• Access the Enterprise Agent Manager (EAM) module to include your groov device to an enterprise managing multiple Ignition gateways

Choose the GROOV-LIC-EDGE8 development license to get these same features without the local visualization (Perspective module) option.

NOTES:

• If you already have a GROOV-LIC-EDGE8 installed on your EPIC, contact Inductive Automation to upgrade your license to Panel.

• With both groov EPICs and groov RIO MM2s, you can use Ignition Edge Panel on a trial basis for two hours at a time, and you can restart the trial as often as you want. Purchasing and installing this license removes the time limit. If you want to use full Ignition, not Ignition Edge Panel, you need a different license. Contact us for more information.
• If you are activating a groov hardware product and a license product at the same time:
  • For groov EPIC processors, first activate the processor, then activate GROOV-LIC-EDGE8-PANEL.
  • For groov RIO MM2s, first activate GROOV-LIC-EDGE8-PANEL, then provide the RIO's serial number. (RIO hardware does not need to be activated.)

  For specific instructions, review the user’s guide for your hardware product.
