$393.00 (USA and Canada only)
Input Range with ICTD Probe
-40 °C to +100 °C
Module Input Range Zero Scale Full Scale
-273 °C +150 °C
Resolution
0.017 °C
Accuracy with ICTD Probe
±0.8 °C
Sensitivity
1.0 microamps/ °C
Data Freshness (Max)
167 ms (2-channel module) 355 ms (4-channel module)
DC Common Mode Rejection
>-120 dB
AC Common Mode Rejection
>-120 dB @ 60 Hz
Maximum Operating Common Mode Voltage
250 V
Isolation
1500 V
Power Requirements
5 VDC (± .015 ) @ 150 mA
Operating Temperature
-20 °C to 70 °C
Storage Temperature
-40 °C to 85 °C
Humidity
5-95%, non-condensing
Wire size
22 to 14 AWG
Torque, hold-down screws
Not to exceed 1 in-lb (0.11 N-m)
Torque, connector screws
5.22 in-lb (0.59 N-m)
Agency Approvals
UL, CE, RoHS, DFARS; UKCA
Warranty
Lifetime
