SNAP-AIV-HDB-FM
Hover over image to zoom in

SNAP-AIV-HDB-FM

Availability: Obsolete
OBSOLETE Breakout Board for SNAP-AIV-32 Analog Input Module

Production Specification

*** NOTE: This part is obsolete and no longer available. ***
Please consider
SNAP-AIV-HDB or contact Opto 22 Pre-Sales engineers for more information.

The SNAP-AIV-HDB is a convenient breakout board for wiring field devices to a 32-channel SNAP-AIV-32 analog input module.

Use the SNAP-HD-BF6 cable to connect the module to the breakout board.

For reference: Modules, Cables, and Breakout Boards Compatibility Charts

Build your system in the SNAP I/O Configurator.
Specifications are not currently available for this product.

Opto 22 RoHS 3 Statement of Compliance - Restriction of Hazardous Substances

This document is a statement of compliance with the EU Directive 2015/863/EU, Restriction of Hazardous Substances (RoHS 3). This document lists Opto 22 products that comply with the substance restrictions of the RoHS 3 directive.

CE Declaration: Low Voltage

This document is the Manufacturer's Declaration for the listed products as mentioned in the attachment - to which this confirmation refers - that they are in accordance with the mentioned European, international and/or national standards and regulations.

No downloads are available for this product.
