*** NOTE: This part is OBSOLETE and no longer available. Use the SNAP-PAC-S1 instead. ***
Now developer and IoT ready with a built-in HTTP/HTTPS server and RESTful API. See Programming, below.
** Compatible with groov EPIC
. You can control groov EPIC I/O units with a SNAP PAC S-series controller running PAC Control R10.a or higher
The SNAP-PAC-S1-FM programmable automation controller provides powerful, real-time control and communications to meet your industrial control, monitoring, and data acquisition needs.
One of the four components of the SNAP PAC System, the SNAP-PAC-S1-FM is fully integrated with PAC Project software, SNAP PAC I/O processors, and SNAP I/O modules to form a complete control system. The SNAP PAC System includes digital and analog control, serial string handling, PID loops, and enterprise connectivity.
The SNAP-PAC-S1-FM is programmed using the included PAC Control software. PAC Control is a flowchart-based tool for developing control applications, or strategies
. You create and debug the strategy on your computer and then download it to the PAC, where it runs independently.
All I/O point and strategy variable data is available for secure access using the built-in HTTPS server and RESTful API, with data delivered in JSON format. For complete API documentation and steps for getting started, see developer.opto22.com
. In addition, two Node-RED nodes are available. Note that minimum firmware R9.5a
and PAC Project R9.5a
are required to use the REST API.
You can build full-featured operator interfaces (HMIs) using the included PAC Display software, which taps the same tagname database you've already developed in PAC Control. SNAP PAC S-series controllers are also compatible with Opto 22's groov products
View HMI tool.
The controller is compact and industrially hardened. It includes two independent Ethernet network interfaces with separate IP addresses, which can be used to segment the control network from the company network or for redundant Ethernet network links.
The SNAP-PAC-S1-FM also has three serial ports: an RS-232 port with full hardware handshaking, ideal for PPP communication using a modem; another RS-232 port for connecting directly to serial devices; and an RS-485 port for connecting to SNAP PAC Serial brains or to legacy mistic
I/O units. (Note: If you are using the S1 with mistic
I/O units, use the legacy versions of the PAC Control, PAC Display, and PAC Manager guides.)
For more details, see the Specifications tab and the Data Sheet.
To compare controller features, see the SNAP PAC Controller and Brain Comparison Chart
