G4DA5
Hover over image to zoom in

G4DA5

Availability: Obsolete
OBSOLETE G4 0 to +10 VDC Analog Output

Production Specification

*** NOTE: This part is obsolete and no longer available. ***

G4 I/O family

The G4DA5 provides a single channel of transformer and optically isolated digital-to-voltage conversion. Output voltage is 0-10 VDC. This module also includes complete electrical channel-to-channel isolation, which eliminates troublesome ground loop problems.



G4DA4 *

G4DA5*

G4DA6**

G4DA7**

Output Voltage

0 to 5 VDC

0 to 10 VDC

-5 to +5 VDC

-10 to +10 VDC

Accuracy

±5 mV

±10 mV

±10 mV

±20 mV

* This product is Obsolete and no longer available.
** This product is Obsolete and no longer available when stock is depleted.

Maximum Output current

20 mA

Output response time

Full scale step change in 3 ms

Resolution

12 bits

Isolation (Transient)
  Input-to-output
  Input-to-analog supply



4,000 Vrms
4,000 Vrms

Ambient temperature
  Operating
  Storage



0 to 70 °C
-25 to 85 °C



G4 Analog Voltage DC Output Modules Data Sheet

G4 analog voltage output modules provide a single channel of transformer and optically isolated digital to voltage conversion. This data sheet includes:

  • G4DA4 [Obsolete, no longer available]
  • G4DA5 [Obsolete, no longer available]
  • G4DA6 [Obsolete, available until current stock is depleted]
  • G4DA7 [Obsolete, no longer available]

Declaration of Conformity (EMC, LVD, RoHS)

This document is the Manufacturer's Declaration of Conformity for the products listed herein, in accordance with European, international, and/or national standards and regulations.

Opto 22 RoHS 3 Statement of Compliance - Restriction of Hazardous Substances

This document is a statement of compliance with the EU Directive 2015/863/EU, Restriction of Hazardous Substances (RoHS 3). This document lists Opto 22 products that comply with the substance restrictions of the RoHS 3 directive.

UL Approval Document

This document lists all Opto 22 part numbers that have the Underwriters Laboratory (UL) approval.

CE Declaration: EMC

This document is the Manufacturer's Declaration for the listed products as mentioned in the attachment - to which this confirmation refers - that they are in accordance with the mentioned European, international and/or national standards and regulations.

CE Declaration: Low Voltage

This document is the Manufacturer's Declaration for the listed products as mentioned in the attachment - to which this confirmation refers - that they are in accordance with the mentioned European, international and/or national standards and regulations.
