PAC-INT-DNP3

$0.00 (USA and Canada only)

Availability: In stock
DNP3 Integration Kit for PAC Control

Please call (800) 321-6786 to order.

PAC-INT-DNP3

Production Specification

The DNP3 Integration Kit for PAC Control allows Opto 22 SNAP PAC controllers, using PAC Control™, to connect via an Ethernet network or serial port and communicate using DNP3, the Distributed Network Protocol.

The integration kit contains:
  • An example DNP3 strategy containing the DNP3 charts that are imported into a strategy to enable an Opto 22 controller to communicate as a DNP3 Level 2 Master or Outstation.
  • A set of PAC Control subroutines that are added to a strategy to add DNP Events.
  • A PAC Control subroutine that is used by the DNP3_Master chart.
  • An Error Handler chart to manage I/O and log errors.
To use the DNP3 subroutines in your PAC Control strategy, you need PAC Control Professional 8.1a or higher.


README for DNP3 Integration Kit for PAC Control

README file for DNP3 Integration Kit for PAC Control

User's Guide: DNP3 Integration Kit for PAC Control

The DNP3 Integration Kit for PAC Control allows Opto 22 SNAP PAC controllers, using PAC Control™, to connect via an Ethernet network or serial port and communicate using DNP3, the Distributed Network Protocol.

This guide describes the kit and how to use the kit.
